37
Member of Exel group
DRT582221110
B - 2023/01
• Step 4:
Apply grease (PTFE) to the seat-holder (4). threads.
ATTENTION: If the springs (9.1 & 10.1) are not removed, go
to step 5, otherwise go to step 6.
• Step 5:
Press the trigger (5) to move the needle (9.4) back.
• Step 6:
Tighten the seat holder (4) in the gun.
Tightening torque: 24 Nm / 17.7 ft-lb.
• Step 7:
Release the trigger (5).
• Step 8:
Screw the aircap (2) on the gun body (1).
5
4
5
2
