DRT582221110
B - 2023/01
8.1.2.3. Tips
(*)
Level 1: 1st emergency parts
Level 2: Wear parts
Tip chart (Tips with stainless steel insert-holder)
Standard tips
Specific tips for water-based paints
To obtain tip part number, replace the crosses by the engraved tip number preceded by 134 5xx xxx.
Example: use part number 134 509 094 to obtain tip 09.094.
Item Part number Description Qty
Sales
unit
Spare parts
level (*)
3
134 5xx xxx Tip 1 1 1 - 2
3.1
129 529 903
Airmix
®
tip seal (package of 10)
- Only for tips size 09 and above
1 1 1 - 2
3.2
129 609 901 Microfilter n°4 / 100µ for tip (package of 10)
- Only for tips size 03, 04 and 06
1 1 1 - 2
Water output (l/mm) Mesh number for filter
Spray fan width at 25 cm / 10’’
With aircap
Maximum (cm)
Size Ø mm
Pressure (bar/psi) 9 12 17
21 25 29 33 37 44 56
35
bar/
500
psi
70
bar/
1000
psi
120
bar/
1740
psi
200
bar/
2900
psi
Gun Pump
Maximum (’’)
3.5 4.7 6.7
8 10 12 13 14.5 17.3 22
Number engraved on the tip
02 0,15 0,07 0,10 0,13 0,17 4 2 02.034 02.054
02.114
03 0,18 0,11 0,15 0,20 0,26 4 2 03.034 03.054 03.074 03.134
04 0,23 0,16 0,22 0,29 0,38 4 2 or 4 04.034 04.054 04.074
04.094 04.114 04.134
06 0,28 0,23 0,33 0,43 0,57 4 4 or 6 06.034 06.054 06.074 06.094 06.114 06.134 06.154
07 0,30 0,28 0,39 0,51 0,66 6 4 or 6
07.154
09 0,33 0,32 0,45 0,59 0,77 6 6 or 8 09.034 09.054 09.074 09.094 09.114 09.134 09.154 09.174
12 0,38 0,42 0,60 0,79 1,03 6 8 or 12 12.074
12.094 12.114 12.134 12.154 12.174
14 0,41 0,51 0,72 0,94 1,23 12 8 or 12 14.034 14.054 14.074 14.094 14.114 14.134 14.154 14.174
18 0,48 0,67 0,95 1,24 1,63 12 12 18.094
18.134 18.154 18.174 18.194
20 0,50 0,76 1,06 1,39 1,82 12 12 20.074 20.094 20.114 20.134 20.154 20.174 20.194
25 0,56 0,94 1,33 1,74 2,28 12 15 25.134 25.174 25.194
30 0,61 1,13 1,60 2,09 2,74 12 15 30.114 30.134 30.154 30.174 30.194
40 0,72 1,54 2,18 2,85 3,73 12 20 40.174 40.214
45 0,76 1,68 2,38 3,12 4,08 12 20 45.114 45.154 45.174 45.194
100 1,04 3,96 5,68 7,33 9,47 12 20-30 100.174 100.214
04 0,23 0,16 0,22 0,29 0,38 4 2 or 4 04.032 04.052 04.072
04.092 04.112 04.132
06 0,28 0,23 0,33 0,43 0,57 4 4 or 6 06.032 06.052 06.072
06.092 06.112 06.132 06.152
07 0,30 0,28 0,39 0,51 0,66 6 4 or 6 07.152
09 0,33 0,32 0,45 0,59 0,77 6 6 or 8 09.032 09.052 09.072
09.092 09.112 09.132 09.152
12 0,38 0,42 0,60 0,79 1,03 6 8 or 12 12.072 12.092 12.112 12.132 12.152 12.172
14 0,41 0,51 0,72 0,94 1,23 12 8 or 12 14.052 14.072 14.092 14.112 14.132 14.152 14.172
Optimum fan adjustment
3
3.1
3.2
