Samson 373 Series Operating Instructions

EB 8389 EN 117
Appendix
Code
No.
Parameter – Readings/
values [default setting]
Description
Codes with marked with an asterisk (*) must be enabled with Code3 prior to conguration.
48* t2 Final_Position_Value.
Value
Current valve position in relation to the working range and its status
t3 Final_Position_Value.
State
t4 AO Feedback Value Current valve position [OUT_SCALE] and its status
t5 AO Feedback State
t6 AO Final_Value.Value Output value [FVR] and its status
t7 AO Final_Value.State
t8 AO Final_Position_
Value.Value
Current valve position [FVR] and its status
t9 AO Final_Position_
Value.State
Resource Block S
S0 Resource target mode Desired operating mode
1)
S1 Resource actual mode Current operating mode
1)
DI1 Function Block I
I0 Target mode DI1 Desired operating mode
1)
I1 Actual mode DI1 Current operating mode
1)
I2 DI1 Trd PV_D.Value Discrete input variable and its status
I3 DI1 Trd PV_D.State
I4 DI1 Fb Target Mode Target operating mode
I5 DI1 Fb Actual Mode Current operating mode
I6 DI1 Fb OUT_D.Value Discrete output variable and its status
I7 DI1 Fb OUT_D.State
I8 DI1 FSAFE_VAL_D Default when the sensor registers an error
I9 Simulate Simulation
DI2 Function Block L
L0 Target Mode DI2 Desired operating mode
1)
