22 EB 8389 EN
Monitoring
The condensed state is marked by until
the positioner data have been uploaded.
Diagnostics > Status messages
Condensed state (Code 48 - d6)
The condensed state can be read in the posi-
tioner display in Code 48 - d6 (see Table3).
3.2.1 Condensed state at the
fault alarm output
3730-2 3730-3 3731-3 3730-4 3730-5 3731-5
In positioners with a fault alarm output, the
condensed state can also be read out at the
fault alarm output if one of the following
conditions occurs:
1. Condensed state 'Maintenance alarm' is
activated.
2. Condensed state 'Function check' is acti-
vated and the fault alarm output is acti-
vated.
3. Condensed state 'Maintenance required'
is activated and the fault alarm output is
activated.
2.
Settings > Positioner > Error control
Fault alarm at condensed state 'Function
check' (Code 32): [Yes]
3. Fault alarm at condensed state 'Mainte-
nance required' (Code 33): [Yes]
Note
3.3 Logging
The last 30 generated messages are saved in
the positioner with a time-stamp (logged by
the operating hours counter).
You can view these messages in TROVIS-
VIEW in the Diagnosis folder (> Status
messages > Logger).
If the positioner is tted with a solenoid
valve, a triggering of the solenoid valve
can only be logged when 'Logging of int.
solenoid valve' is activated.
In the event the solenoid valve is triggered
again, this is only logged when the 'Min.
clearance new logging int. solenoid valve'
has elapsed since the last triggering.
Settings > Positioner > Error control
Logging of int. solenoid valve
1)
: [Yes], No
Min. clearance new logging int. solenoid valve
1)
:
0 to 5000 s, [300 s]
1)
Not Type3730-4
