Monitoring
Function
Resetting
single status
messages
Code
36 - Diag
Code
36 - Std
Drive signal
diagram hysteresis
(d2)
Reference values NO NO YES
Measured values YES YES
YES
Static characteristic (d3) NO YES YES
Partial stroke test (PST) (d4) YES NO YES
Full stroke test (FST) (d6) YES NO YES
Leakage sensor
Reference test
1), 3)
NO NO YES
Repetition test
1), 3)
YES NO YES
Short-term monitoring
1), 3)
NO YES YES
Long-term monitoring
1), 3)
NO YES YES
Sound level monitoring
1), 3)
NO YES YES
1)
Not Type3730-4
2)
Not Type3730-5 (1.6x)
3)
Not Type3731-5
Table3: Condensed state reading
Status message TROVIS-VIEW 4/DTM Positioner Priority
Function check
1)
orange
Text e.g. tESting, tunE or
tESt
Maintenance alarm
red
Out of specication/invalid
process state
1)
yellow
blinking
Maintenance required/
maintenance demanded
blue
No message, OK
green
1)
Not Type3730-5 (1.5x)
