Samson 373 Series Operating Instructions

EB 8389 EN 119
Appendix
Code
No.
Parameter – Readings/
values [default setting]
Description
Codes with marked with an asterisk (*) must be enabled with Code3 prior to conguration.
F3 Simulate Activation of simulation mode
48* AO Function Block
A0 Target mode Target operating mode
A1 Actual mode Current operating mode
A2 CAS_IN value
Analog set point adopted from an upstream function block and its
status
A3 CAS_IN status
A4 SP value
Set point and its status
A5 SP status
A6 Out value
Manipulated variable (output value) and its status
A7 Out status
A8 Block error Current block error
PID Function Block (PID)
P0 Target mode Target operating mode
P1 Actual mode Current operating mode
P2 CAS_IN Value
Analog set point adopted from an upstream function block and its
status
P3 CAS_IN Status
P4 SP value
Set point and its status
P5 SP status
P6 Out value
Manipulated variable (output value) and its status
P7 Out status
P8 Block error Current block error
Transducer Blocks A0, DI1, DI2
t0 Target mode AO Trd Target operating mode
t1 Actual mode AO Trd Current operating mode
t2 Transducer state State of the Transducer Block
t3 Block error AO Trd Current block error
