Samson 373 Series Operating Instructions

26 EB 8389 EN
START-UP
Prerequisite:
– Application type: open/close (on/off)
â
Operating point, Limit fail-safe position, Limit operating point
â
Limit value travel analysis
Limit value time analysis
Status classication (NE107)
Open/Close status active
Dene parameters for partial
stroke test (see section5.4)
â â
On/off diagnosis Discrete set point analysis PST
x [%
]
w [%
]
t [s]
∆t > 6 s
25
50
x [%]
w [%]
t [s]
â
First analysis after dening parameters =
Reference
PROCESS
Breakaway time, transit
time, valve end position
(rising/falling)
â â
Analysis (NE107)/
logged by operating hours counter
Open/Close status active
Analysis (see section5.4)
â
Reset measured data 'Open/Close'
Reset all parameters 'Open/Close'
Statistical information – On/off diagnosis
