Samson 3730 Series User Manual

7-10 EB 8384-3 EN
Start-up and conguration
1. Turn untilCode3appears(reading:
No).
2. Press , the code number 3 blinks.
3. Turn until YES appears.
4. Press toconrm(reading: ).
Enableconguration
Default: No
Enter the pin position and nominal range:
1. Turn untilCode4appears.
2. Press , the code number 4 blinks.
3. Turn to select pin position on lever (see
relevant section on attachment).
4. Press toconrm.
mm
Pin position
Default: No
5. Turn untilCode5appears.
6. Press , the code number 5 blinks.
7. Turn and set rated travel of the valve.
8. Press toconrm.
mm
Nominal range
(lockedwhenCode4=
No)
Select the initialization mode:
1. Turn untilCode6appears.
2. Press , the code number 6 blinks.
3. Turn until NOM appears.
4. Press toconrmtheNOMinitialization
mode.
Init mode
Default: MAX
Start initialization:
Î Press INIT key.
Î After the initialization has been successfully completed:
Checkthedirectionofaction(Code7)and,ifnecessary,changeit.
