Samson 3730 Series User Manual

EB 8384-3 EN 3-5
Design and principle of operation
3.5 Technical data
Table 3-1: Type3730-3 Electropneumatic Positioner
Type3730-3 Positioner
The technical data for the explosion-protected devices may be restricted by the
limits specied in the test certicates.
Valve
travel
Adjustable
DirectattachmenttoType3277Actuator 3.6to30mm
AttachmentaccordingtoIEC60534-6
(NAMUR)
3.6to300mm
AttachmentaccordingtoVDI/VDE3847 3.6to300mm
Attachmenttorotaryactuators(VDI/
VDE3845)
24to100°openingangle
Travel
range
Adjustable
Adjustablewithintheinitializedtravel/angleofrotationofthevalve;travelcanbe
restrictedto1/5atthemaximum.
Set point
w
Signal range 4to20mA·Two-wiredevice,reversepolarityprotection·Minimumspan4mA
Static destruction
limit
100mA
Minimum current 3.6mAfordisplay·3.8mAforoperation
Load impedance ≤8.2V(correspondsto410Ωat20mA)
Supply
Supply air 1.4to7bar(20to105psi)
Air quality acc. to
ISO8573-1
Max. particle size and density: Class 4 · Oil content: Class 3 · Pressure dew point:
Class 3 or at least 10 K below the lowest ambient temperature to be expected
Signal pressure (output)
0baruptothesupplypressure·Canbelimitedto1.4bar/2.4bar/3.7bar
±0.2barbysoftware
Charac-
teristic
Adjustable
Linear/Equalpercentage/Reverseequalpercentage
User-dened(overoperatingsoftwareandcommunication)
Butteryvalve,rotaryplugvalveandsegmentedballvalve:Linear/equalpercent-
age
Deviation ≤1%
Hysteresis ≤0.3%
Sensitivity ≤0.1%
Transit time Exhaustandsupplyadjustableseparatelyupto240sbysoftware
Direction of action Reversible
Air consumption, steady state Independentofsupplyairapprox.110l
n
/h
Air out-
put ca-
pacity
Actuator (supply) AtΔp=6bar:8.5m
n
³/h·AtΔp=1.4bar:3.0m
n
³/h·K
Vmax(20°C)
=0.09
Actuator (exhaust) AtΔp=6bar:14.0m
n
³/h·AtΔp=1.4bar:4.5m
n
³/h·K
Vmax(20°C)
=0.15
Permissible ambient temperature
–20to+80°C All versions
–45to+80°C Withmetalcablegland
–55to+80°C Special version for low temperatures with metal cable gland
(Type3730-3xxxxxxxx0x02x0xx)
The temperature limits for the explosion-protected devices may be restricted by
the limits specied in the test certicates.
