Samson 3730 Series User Manual

EB 8384-3 EN 2-1
Markings on the device
2 Markings on the device
2.1 Nameplate
Version without explosion
protection
Explosion-protected version
* Conductive: R =348 Ω
i
PLC-compatible: VDC ≤ + 35V
Fault indicator *
Position indicator
Output 4 to 20 mA DC
U = 24 V DC
n
Solenoid valve
Limit switches, software *
Binary input
Leakage detection
Limit switch, inductive
Input 4 to 20 mA DC
Analog input signal x
3730-3
Input
Supply
HART
R
capable Positioner
See technical data for
ambient temperature
Firmware
SAMSON AG D-60314 Frankfurt Made in Germany
Model
Var.-ID
Diagnostics EXPERTplus
Date
Serial no.
1
2
3
3
3
3
3
3
3
3
4
5
6 7
8
9
10
Input
Binary input*
Leakage detection*
(–40 °C)
* See technical data and
explosion-protection
certificate for permissible
ambient temperature
and maximum values for
connection to certified
intrinsically safe circuits.
3730-3
Supply
Firmware
SAMSON AG D-60314 Frankfurt
Made in Germany
Model
Var.-ID
Diagnostics EXPERTplus
Date
HART
R
capable Positioner
Serial no.
Fault indicator*
Position indicator*
Limit switch, inductive*
Limit switches, software*
Solenoid valve*
10
9
1
2
3
3
3
3
3
3
3
4
5
6 7
8
11
1 Supply pressure
2 Input signal (4 to 20 mA DC)
3 Features: Yes/ No
− Fault indicator
− Position indicator
4to20mADCoutput
− Analog input signal x
4 to 20 mA DC
− Binary input
− Leakage detection
− Limit switch, inductive
− Limit switches, software
− Solenoid valve
4 Date of manufacture
5 Firmware version
6 CongurationID
7 Serial number
8 Model number
9 Approvals (CE, EAC, UKCA etc.)
10 Data Matrix code
(electronic nameplate)
11 Explosion protection marking
