Checklist:
Device: Plant: Process designation: Date:
Selection
option/
block
Designation Range of values Factory
default
Start-up
values/
modifications
Configuration level:
In
Type of input signal 0 to 5 1
In__
Min. measuring range limit X Depending on In –100.0
In
—
Max. measuring range limit X Depending on In 400.0
Ind
Decimal point 0 to 3 1
In0
Range selection current/voltage 0 or 1 1
Int
Unit of temperature °C/°F 0 or 1 0
InF
Digital filter 0.0 to 120.0 s 0.5
dI
D-action component 0 or 1 0
SP
Selection of setpoint (SP) 0 to 4 0
SPr
Setpoint ramp 0 to 9999 s 0
SPH
Inhibition of setpoint modification 0 to 3 0
YH
Lock MANUAL/AUTOMATIC key 0 to 2 0
Y
Select controller output 0 to 2 0
Yr
Operating direction 0 or 1 1
Y0
Select the current range output 0 or 1 1
YSt
Safety output (restart) value –110.0 to 110.0 % –10.0
Y1
Limit alarm condition 0 to 9 0
Y1C
Make or break contact Y1 0 or 1 0
Y2
Limit alarm condition 0 to 9 0
Y2C
Make or break contact Y2 0 or 1 0
AdP
Adaption 0 or 1 0
CPA
Code no. of parameterization level 0 to 9999 0
CCO
Code no. of configuration level 0 to 9999 0
35
