* Due to technical reasons, the term control deviation XD has been used to represent the
setpoint error (e = w – x). The correct abbreviation reads correctly as e.
Control deviation
display (10)*
Controller output
display (10)
Setpoint (SP)
display (10)
Control deviation
display (3)*
Switching output
display (4)
ENTER key (8)
Unit of temperature label
Controlled variable display
(or value specification)
Setpoint (SP) display
(or entry option)
Operating key (7)
Cursor keys (5)
MANUAL/AUTOMATIC
key (6)
Setpoint (SP) key (9)
Front view
