2.2.6 Connecting to a Secondary Monitor
1 Connect the DVI cable to [DVI IN] on the back of the product and [DVI OUT] on the stand base.
2 Connect the D-SUB cable to [RGB OUT] on the stand base and [RGB IN] on the secondary monitor.
3 Connect the DC power adapter to the product and a power outlet. Next, turn on the power switch
on the stand base.
(For details, refer to "3.3 Connecting the Power".)
z The [RGB OUT] port can be used only to connect to a secondary monitor.
z By removing all the cables from the stand, you can connect the monitor to a PC to use it as a PC
monitor.
DVI IN
DVI OUT
RGB INRGB OUT
