520-222-000 1/04 Rev C Model S30 Metallic Design Level 1 Page 15
ITEM PART NUMBER DESCRIPTION QTY
1 **031-146-000 Air Valve Assembly 1
**031-147-000 Air Valve Assembly 1
**031-173-000 Air Valve Assembly 1
031-183-000 Air Valve Assembly 1
031-179-000 Air Valve Assembly (Cast Iron Centers Only) 1
2 050-014-354 Ball, Check 4
050-014-360 Ball, Check 4
050-014-364 Ball, Check 4
050-014-365 Ball, Check 4
050-015-600 Ball, Check 4
3 070-006-170 Bushing 2
4 095-110-558 Pilot Valve Assembly 1
095-110-110 Pilot Valve Assembly (Cast Iron Centers Only) 1
5 114-024-157 Intermediate Bracket 1
114-024-010 Intermediate Bracket 1
6 132-035-360 Bumper, Diaphragm 2
7 135-034-506 Bushing, Plunger 2
8 165-113-157 Cap, Air Inlet Assembly 1
165-113-010 Cap, Air Inlet Assembly 1
9 170-055-115 Capscrew, Hex Hd 1/2-13 X 2.50 16
170-055-330 Capscrew, Hex Hd 1/2-13 X 2.50 16
10 170-060-115 Capscrew, Hex Hd 7/16-14 X 2.00 16
170-060-330 Capscrew, Hex Hd 7/16-14 X 2.00 16
11 170-069-115 Capscrew, Hex Hd 5/16-18 X 1.75 4
170-069-330 Capscrew, Hex Hd 5/16-18 X 1.75 4
12 171-053-115 Capscrew, Soc Hd 3/8-16 X 2.50 (Stroke Indicator Only) 4
171-053-330 Capscrew, Soc Hd 3/8-16 X 2.50 (Stroke Indicator Only) 4
170-006-115 Capscrew, Hex HD 3/8-16 X 1.00 4
170-006-330 Capscrew, Hex HD 3/8-16 X 1.00 4
13 171-059-115 Capscrew, Soc Hd 7/16-14 X 1.25 8
171-059-330 Capscrew, Soc Hd 7/16-14 X 1.25 8
14 196-164-156 Chamber, Outer 2
196-164-015 Chamber, Outer 2
196-164-110 Chamber, Outer 2
196-164-112 Chamber, Outer 2
15 196-165-156 Chamber, Inner 2
196-165-010 Chamber, Inner 2
16 286-098-604 Diaphragm, Overlay 2
17 286-098-360 Diaphragm 2
286-098-363 Diaphragm 2
286-098-354 Diaphragm 2
286-098-365 Diaphragm 2
18 360-093-360 Gasket, Air Valve 1
19 360-103-360 Gasket, Pilot Valve 1
20 360-104-379 Gasket, Air Inlet 1
21 360-105-360 Gasket, Inner Chamber 2
22 518-143-156 Manifold, Suction 1
518-143-156E Manifold, Suction 3" BSPT 1
518-143-010 Manifold, Suction 1
518-143-010E Manifold, Suction 3" BSPT 1
518-143-110 Manifold, Suction 1
518-143-110E Manifold, Suction 3" BSPT 1
518-143-112 Manifold, Suction 1
518-143-112E Manifold, Suction 3' BSPT 1
23 518-144-156 Manifold, Discharge 1
518-144-156E Manifold, Discharge 3" BSPT 1
518-144-010 Manifold, Discharge 1
518-144-010E Manifold, Discharge 3" BSPT 1
518-144-110 Manifold, Discharge 1
518-144-110E Manifold, Discharge 3" BSPT 1
518-144-112 Manifold, Discharge 1
518-144-112E Manifold, Discharge 3" BSPT 1
24 545-007-115 Nut, Hex 7/16-14 16
545-007-330 Nut, Hex 7/16-14 16
25 545-008-115 Nut, Hex 1/2-13 16
545-008-330 Nut, Hex 1/2-13 16
26 560-001-360 O-Ring 2
27 560-105-360 Seal (O-Ring) (See item 34) 8
560-105-363 Seal (O-Ring) (See item 34) 8
560-105-364 Seal (O-Ring) (See item 34) 8
560-105-365 Seal (O-Ring) (See item 34) 8
720-055-608 Seal (O-Ring) (See item 34) 8
28 612-192-157 Plate, Inner Diaphragm Assembly 2
612-192-010 Plate, Inner Diaphragm Assembly 2
29 612-194-157 Plate, Outer Diaphragm Assembly 2
612-194-010 Plate, Outer Diaphragm Assembly 2
612-194-110 Plate, Outer Diaphragm Assembly 2
612-194-112 Plate, Outer Diaphragm Assembly 2
30 620-020-115 Plunger, Actuator 2
31 675-042-115 Ring, Retaining 2
32 685-040-120 Rod, Diaphragm 1
33 720-004-360 Seal, Diaphragm Rod 2
34 722-090-360 Seat, Check Ball 4
722-090-363 Seat, Check Ball 4
722-090-364 Seat, Check Ball 4
722-090-365 Seat, Check Ball 4
722-090-600 Seat, Check Ball 4
722-090-080 Seat, Check Ball (seals required see item 27) 4
722-090-110 Seat, Check Ball (seals required see item 27) 4
722-090-150 Seat, Check Ball (seals required see item 27) 4
35 901-038-115 5/16 Flat Washer 4
901-038-330 5/16 Flat Washer 4
36 901-048-115 3/8 Flat Washer (Stroke Indicator Only) 4
901-048-330 3/8 Flat Washer (Stroke Indicator Only) 4
42 530-033-000 Metal Muffler 1
(for other muffler options see pg. 26)
ITEM PART NUMBER DESCRIPTION QTY
**Note: Pumps equipped with these components are not ATEX compliant
