Sandpiper S30 - Dimensions with Spill Containment; S30 Non-Metallic Dimensions with Spill Containment

520-222-000 1/04 Rev C Model S30 Metallic Design Level 1 Page 6
Dimensions: S30 Metallic
Dimensions in Inches
Dimensional Tolerance:±
1
/8"
Discharge Port
3" NPT
Both Sution And
Discharge Ports Are
Available With
3" BSP Tapered Connection
Center Of Gravity
Suction Port
3" NPT
1 3/4"
To Center
Of Gravity
Standard Encapsulated Muffler
1" NPT Exhaust Port
For Optional Muffler
Styles Or Piping Exhaust
Air In Submerged
Applications
Air Inlet
3/4" NPT
Pulse Output Kit
Aluminum
Sound Dampening Muffler
Encapsulated Muffler
Stainless Steel
Metal Muffler
DIMENSION
B
C
D E
15 3/4
16 1/32
29 31/32
2 11/32 17 9/64 32 1/16
30 3/16 2 9/16 17 23/64 32 9/32
Mesh Muffler
17 3/16
17 3/16
16 3/4
A
