520-222-000 1/04 Rev C Model S30 Metallic Design Level 1 Page 2
Pump Brand
S= SandPIPER
®
Pump Size
30=3"
Check Valve Type
B= Ball
Design Level
1= Design Level
Wetted Material
A= Aluminum
I = Cast Iron
S= Stainless Steel
H= Alloy C
Diaphragm Check Valve Materials
1= Santoprene/Santoprene
B= Buna/Buna
C=Viton/PTFE
E=EPDM/EPDM
G=PTFE -Neoprene/PTFE
I= EPDM/Santoprene
N=Neoprene/Neoprene
V=Viton/Viton
Check Valve Seat
A= Aluminum B=Buna
C=Carbon Steel E=EPDM
N=Neoprene S=Stainless Steel
T= PTFE V=Viton
Non-Wetted Material Options
A= Painted Aluminum
I= Cast Iron
J= Painted Aluminum w/PTFE
Coated Hardware
Y= Painted Aluminum w/
Stainless Steel Hardware
Z= Cast Iron with Stainless
Steel Hardware
Porting Options
N=NPT Threads
B= BSPT (Tapered) Threads
Pump Style
S= Standard
Pump Options
0= None
1= Sound Dampening Muffler
2= Mesh Muffler
3= High temperature Air Valve
w/Encapsulated Muffler
4= High temperature Air Valve
w/Sound Dampening Muffler
5= High temperature Air
Valve w/Mesh Muffler
6= Metal Muffler**
S30 Metallic · Design Level 1· Ball Valve
Explanation of Pump Nomenclature
Kit Options
00.=None**
P0.=0-30VDC Pulse Output Kit
P1.=Intrinsically-Safe 10-30VDC
Pulse Output Kit
P2.=110/120 or 220/240VAC
Pulse Output Kit
P3.=Intrinsically-Safe 110/120VAC
Pulse Output Kit
P4.=Intrinsically-Safe 220/240VAC
Pulse Output Kit
SP.=Stroke Indicator Pins
Check Diaphragm/ Check Non-Wetted Shipping
MODEL Pump Pump Valve Design Wetted Check Valve Valve Material Porting Pump Pump Kit Weight
Brand Size Type Level Material Materials Seat Options Options Style Options Options lbs. (kg)
S30B1ABBANS000. S 30 B 1 A B B A N S 0 00. 116 (53)
S30B1AEEANS000. S 30 B 1 A E E A N S 0 00. 116 (53)
S30B1AGTANS000. S 30 B 1 A G T A N S 0 00. 116 (53)
S30B1ANNANS000. S 30 B 1 A N N A N S 0 00. 116 (53)
S30B1A1EANS000. S 30 B 1 A 1 E A N S 0 00. 116 (53)
S30B1AVTANS000. S 30 B 1 A V T A N S 0 00. 116 (53)
S30B1IBBANS000. S 30 B 1 I B B A N S 0 00. 215 (98)
S30B1IEEANS000. S 30 B 1 I E E A N S 0 00. 215 (98)
S30B1IGTANS000. S 30 B 1 I G T A N S 0 00. 215 (98)
S30B1INNANS000. S 30 B 1 I N N A N S 0 00. 215 (98)
S30B1I1EANS000. S 30 B 1 I 1 E A N S 0 00. 215 (98)
S30B1IVTANS000. S 30 B 1 I V T A N S 0 00. 215 (98)
S30B1IEEANS000. S 30 B 1 I E E A N S 0 00. 215 (98)
S30B1SBBANS000. S 30 B 1 S B B A N S 0 00. 194 (87)
S30B1SGTANS000. S 30 B 1 S G T A N S 0 00. 194 (87)
S30B1SNNANS000. S 30 B 1 S N N A N S 0 00. 194 (87)
S30B1S1EANS000. S 30 B 1 S 1 E A N S 0 00. 194 (87)
S30B1SVTANS000. S 30 B 1 S V T A N S 0 00. 194 (87)
S30B1HGTANS000. S 30 B 1 H G T A N S 0 00. 235 (107)
** Note: ATEX compliant pumps must be ordered with a metal muffler and no kit options
