Intelligent slot
3 Installation
2. Alternative connection of communication
Intelligent Slot: It is designed for installing the AS400 card, SNMP card and
CMC card. You can choose for one of them to installed
a－AS400: You can utilize AS400’s monitor function to manage the power
supply directly.
b－SNMP: It enables you monitor the UPS remotely through Internet.
c －CMC: Central monitor card.
Note: 1. Remove the cover board of the intelligent slot before any card is installed.
2. Refer to some other relative documents for the use of the WinPower
software and the AS400 and SNMP and CMC cards. If you have any
question about the above communication ports, please contact customer
service center.
3. There are two type of card for intelligent slot :short card and long card,
the UPS this manual described match for the short card .
3. Surge-protection connection
a—Output: Connects the equipment to be protected.
b—Input: Connects the telephone line or network.
