3
2 Product Description
The Appearance of the UPS
22.
Computer Interface
Breaker
Input
Intelligent Slot
Surge Protection
Output
External Battery Connector
Figure 2-1 The rear panel of C1KS
External Battery
Connector
Computer Interface
Intelligent Slot
Surge Protection
Output
Breaker
Input
Figure 2-2 The rear panel of C2KS
