SINUS MINI High performance Vector Control Inverter User Manual
13
●The inverter shall not be installed horizontally or horizontally, and vertical and
vertical installation must be guaranteed;
●High resistance heating equipment such as braking resistance, please install
independently, avoid and inverter installed in the same cabinet, it is strictly prohibited
to brake resistance and other high heating equipment installed in the inverter inlet
2.2 Mechanical installation
●SINUS MINI series inverter components
●Installation space, direction and space
Installation: single frequency governor to install in indoor ventilated place, and a wall hanging cabinet type or
vertical installation. And with the adjacent items or baffle (wall) must keep enough space.
installation diagram of single inverter
