SINUS MINI High performance Vector Control Inverter User Manual
9
1.4 Product standard specification
Item
Specifications
power
Voltage frequency
Single-phase 220V50/60Hz, Three-phase 380V 50/60Hz
Allowable fluctuation
voltage：±15%，frequency：±5%
Control
perfor
mance
Frequency range
0-600Hz
Output frequency
precision
The maximum frequency value ±0.1%
Output frequency
resolution
Operate keyboard up and down keys：0.01Hz Potentiometer analog input：0.2Hz
Run command given
mode
The keyboard is given; the external terminal is given; the serial port is given by the
host computer
carrier frequency
2.0-12.0KHz
Torque boost
0~20.0% adjustable, optional v/f curve optional
overload capacity
150% rated output current 1 minute，180% rated output current 2 second
Acc/Dec time
0.1~3600 second
Rated output voltage
Using the power supply voltage compensation function, the motor rated voltage is
100%, which can be set in the range of 50-100% (the output can not exceed the
input voltage)
AVR function
When the network voltage fluctuates, the output voltage fluctuation is very small and
almost constant V/F
standard feature
PID control, acceleration and deceleration time is adjustable, variable deceleration
mode, carrier frequency, torque, current limiting, power off, restart, jump frequency
control, lower frequency running, multi-speed, swing frequency, RS485, analog
output, fault slip compensation, automatic reset
braking
Energy consumption braking, DC braking
Frequency setting input
Keyboard digital setting, external terminal AI1 (0-10V/0-20mA switchable), AI2
(0-10V/0-20mA switchable), RS485 and signal combination and terminal selection
Signal feedback input
External terminal AI1 (0-10V/0-20mA switchable), AI2 (0-10V/0-20mA switchable),
RS485
Input instruction signal
Start, stop, reverse, inching, multi-speed, free parking, reset, acceleration and
deceleration time selection, frequency setting, channel selection, external fault
alarm, etc.
External output signal
Relay output, collector output, 0-10V output, 4-20mA output
protective function
Over voltage, under voltage, over current, current limit, overload, overheating,
electronic thermal overload relay, stall, data protection, etc.
