SINUS MINI High performance Vector Control Inverter User Manual
8
SINUS MINI−4T Three phase AC 380V constant torque / heavy load application
Power（kW）
0.75
1.5
2.2
4.0
5.5
/
/
/
/
/
/
/
/
/
/
Motor
power（kW）
0.75
1.5
2.2
4.0
5.5
/
/
/
/
/
/
/
/
/
/
Out
put
Voltage
（V）
Three-phase 0 to rated input voltage
Rated
current
（A）
2.5
3.7
5.5
9
13
/
/
/
/
/
/
/
/
/
/
Overload
capacity
150% 1 minute，180% 2 seconds， 200% 0.5 seconds，10 minutes (inverse time lag feature)
Inp
ut
Rated
voltage /
frequency
3 phase 380V±15%；50Hz/60Hz
Allowable
voltage
range
380V±15%；Voltage imbalance：≤3% ；Allowable frequency fluctuation：±5%
Rated
current
（A）
4.3
5.2
6.0
10.5
15.5
/
/
/
/
/
/
/
/
/
/
Brake unit
Built-in as standard
External braking unit needed
Protection class
IP30
Cooling mode
Self-
cooling
Forced air convection cooling
SINUS MINI−5T Three phase AC 460V constant torque / heavy load application
Power（kW）
0.75
1.5
2.2
4.0
5.5
/
/
/
/
/
/
/
/
/
/
Motor
power（kW）
0.75
1.5
2.2
4.0
5.5
/
/
/
/
/
/
/
/
/
/
Out
put
Voltage
（V）
Three-phase 0 to rated input voltage
Rated
current（A）
2.5
3.7
5.5
9
13
/
/
/
/
/
/
/
/
/
/
Overload
capacity
150% 1 minute，180% 2 seconds， 200% 0.5 seconds，10 minutes (inverse time lag feature)
Input
Rated
voltage /
frequency
3 phase 460V±15%；50Hz/60Hz
Allowable
voltage
range
460V±15%；Voltage imbalance：≤3% ；Allowable frequency fluctuation：±5%
Rated
current（A）
4.1
4.9
5.7
9.4
12.5
/
/
/
/
/
/
/
/
/
/
Brake unit
Built-in as standard
External braking unit needed
Protection class
IP30
Cooling mode
Self-
cooling
Forced air convection cooling
