SINUS MINI High performance Vector Control Inverter User Manual
14
Multiple installation: when installing multiple inverters in the control cabinet, please ensure the following
installation space.
Installation diagram of multi inverters
2.3 Inverter shape and installation dimensions
Voltage
level
Inverter model
Outline construction and installation dimension（mm）
Weight
（kg）
W
H
D
W1
H1
Mounting hole d
Single
phase
220V
SINUS−0001 2S
78
188
126
55
178
4
1.5
SINUS−0002 2S
SINUS−0003 2S
SINUS−0004 2S
96
225
137
65
215
4
2
Three
-phase
220V
SINUS−0001 2T
78
188
126
55
178
4
1.5
SINUS−0002 2T
SINUS−0003 2T
SINUS−0004 2T
96
225
137
65
215
4
2
