Key No. Part No. Description Key No. Part No. Description
-83-
Electrical Parts List
KR8-XD220000,KS8-XD260000
ASSEMBLED BOARDS
!A2300 655 002 8396 ASSY,PWB R/C KR5AC
!A2200 655 003 7787 ASSY,PWB,POWER KR8AC
!A1000 655 003 7275 ASSY,PWB,MAIN KR8AC
(For KR8-XD220000)
!A1000 655 003 7237 ASSY,PWB.MAIN KS8AC
(For KS8-XD260000)
!A2000 655 003 9064 ASSY,PWB,AUDIO JACK KR8AC
OUT OF CIRCUIT BOARD
!L902 945 003 3835 CORE,FERRITE
652 003 1098 CORE,CLAMP
!L904 945 003 3835 CORE,FERRITE
652 003 1098 CORE,CLAMP
!LP900 610 349 7518 COMPL,OPTICAL LAMP-KR8AC
!A901 645 102 7283 UNIT,BALLAST
A901A 652 003 2330 CABLE,BALLAST KR8AC
!FN001 645 100 1900 MOTOR,BLW DC 2.4W
!FN002 645 100 1917 MOTOR,FAN DC 2.28W
!FN003 645 100 1894 MOTOR,BLW DC 2.4W
!FN004 645 100 1887 MOTOR,BLW DC 2.4W
!FN005 645 100 1887 MOTOR,BLW DC 2.4W
SP901 652 002 4397 SPEAKER,8
!SW902 645 097 3925 SWITCH,MICRO 1P-2T
A2300 655 002 8396 ASSY,PWB R/C KR5AC
CAPACITOR
C2901 303 358 8319 CERAMIC 1U K 10V
C2902 303 157 6615 CERAMIC 470P K 50V
C2903 303 230 3616 TA-SOLID 47U M 6.3V
303 384 4712 TA-SOLID 47U M 6.3V
C8843 303 298 9612 CERAMIC 0.1U K 16V
RESISTOR
R2901 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R2903 301 255 6513 MT-GLAZE 100 JA 1/10W
R8855 301 162 2219 MT-GLAZE 10 JA 1/10W
R8856 301 162 2219 MT-GLAZE 10 JA 1/10W
MISCELLANEOUS
A2901 652 002 3352 UNIT,REMOCON,RECEIVER
A2200 655 003 7787 ASSY,PWB,POWER KR8AC
TRANSISTOR
Q611 305 140 3707 TR 2SK2698
Q641 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q642 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q643 305 217 6600 TR 2SK3934
Q651 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q691 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC621 409 690 7918 IC FA5550N
IC631 309 653 7405 IC MR4010-7101
IC671 409 692 2515 IC TA76L431FB
CAPACITOR
!C601 404 117 6403 MT-POLYEST 1U K 275V
404 117 8902 MT-POLYEST 1U K 310V
!C603 404 121 9605 CERAMIC 3300P M 250V
!C604 404 121 9605 CERAMIC 3300P M 250V
!C605 304 073 3709 CERAMIC 100P K 250V
!C606 304 073 3709 CERAMIC 100P K 250V
C611 303 222 1326 CERAMIC 1000P K 1K
C612 303 222 1326 CERAMIC 1000P K 1K
C613 303 451 4119 MT-POLYEST 1U K 450V
C614 303 451 4119 MT-POLYEST 1U K 450V
C615 404 118 3609 ELECT 150U M 420V
404 123 1706 ELECT 150U M 420V
C621 303 336 3510 CERAMIC 0.47U K 16V
C622 304 091 4504 CERAMIC 0.047U K 50V
C623 304 090 1207 CERAMIC 0.01U K 50V
C625 304 090 1207 CERAMIC 0.01U K 50V
C626 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
403 478 5912 CERAMIC 1U K 25V
C627 304 091 3309 CERAMIC 2200P K 50V
C631 303 157 4215 CERAMIC 220P J 50V
C632 303 247 6627 CERAMIC 680P K 2K
404 111 2401 CERAMIC 680P K 2K
C633 303 265 3216 CERAMIC 1000P J 50V
C634 304 091 3309 CERAMIC 2200P K 50V
C641 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C642 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C644 303 417 9912 CERAMIC 4.7U K 25V
303 452 5016 CERAMIC 4.7U K 25V
C651 304 097 0005 ELECT 100U M 25V
C653 303 367 0410 CERAMIC 0.1U K 50V
303 370 1510 CERAMIC 0.1U K 50V
C661 303 445 4405 ELECT 1800U M 25V
C662 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C663 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C664 303 429 6718 ELECT 1500U M 10V
C665 303 409 9913 ELECT 470U M 16V
C671 304 091 2609 CERAMIC 0.1U K 50V
RESISTOR
!R601 301 242 3914 MT-GLAZE 240K JA 1/2W
To Next Page
