Key No. Part No. Description Key No. Part No. Description
Electrical Parts List
-84-
KR8-XD220000,KS8-XD260000
!R602 301 242 3914 MT-GLAZE 240K JA 1/2W
R611 401 353 0311 MT-GLAZE 430K JA 1/3W
R612 401 353 0212 MT-GLAZE 360K JA 1/3W
R613 301 256 6314 MT-GLAZE 47K JA 1/10W
R614 302 106 5508 RESISTER 0.075 KB 5W
R615 402 122 0409 MT-GLAZE 680K DD 1/4W
R616 402 122 0409 MT-GLAZE 680K DD 1/4W
R621 301 326 1812 MT-GLAZE 8.2K D A 1/10W
R622 301 309 8517 MT-GLAZE 330 DA 1/10W
R623 401 360 8010 MT-GLAZE 470 DA 1/10W
R624 301 162 2912 MT-GLAZE 220 JA 1/10W
R625 301 256 5614 MT-GLAZE 47 JA 1/10W
R626 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R627 301 150 5918 MT-GLAZE 10K JA 1/10W
R628 301 150 5918 MT-GLAZE 10K JA 1/10W
R629 301 255 7312 MT-GLAZE 510K JA 1/10W
R631 301 255 7718 MT-GLAZE 11K JA 1/10W
R632 301 253 3712 MT-GLAZE 0.000 ZA 1/4
301 035 4111 MT-GLAZE 0.000 ZA 1/8W
R633 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R634 301 256 1715 MT-GLAZE 33K JA 1/10W
R635 402 122 1802 OXIDE-MT 0.39JA 1W
302 099 6308 OXIDE-MT 0.39JA 1W
R636 301 162 3018 MT-GLAZE 22K JA 1/10W
R641 301 150 5918 MT-GLAZE 10K JA 1/10W
R642 301 256 6611 MT-GLAZE 68K JA 1/10W
R643 301 150 5918 MT-GLAZE 10K JA 1/10W
R644 301 150 5918 MT-GLAZE 10K JA 1/10W
R646 301 256 7212 MT-GLAZE 18K JA 1/10W
R648 301 256 7212 MT-GLAZE 18K JA 1/10W
R651 301 150 5918 MT-GLAZE 10K JA 1/10W
R652 301 292 1915 MT-GLAZE 22 FA 1/2W
R662 301 152 3219 MT-GLAZE 330 JA 1/10W
R671 301 256 7618 MT-GLAZE 3.9K JA 1/10W
R672 301 150 6212 MT-GLAZE 1K JA 1/10W
R673 301 264 2919 MT-GLAZE 12K FA 1/10W
R674 301 264 7518 MT-GLAZE 2.7K FA 1/10W
R675 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R676 301 264 2810 MT-GLAZE 1.2K FA 1/10W
R683 301 265 0211 MT-GLAZE 390 FA 1/10W
R684 301 264 9314 MT-GLAZE 3.3K FA 1/10W
R691 301 162 2417 MT-GLAZE 1.2K JA 1/10W
R692 301 150 6212 MT-GLAZE 1K JA 1/10W
VARIABLE RESISTOR
!VA601 408 066 1700 VD TND14SE471KB0SLAA0
TRANSFORMER
!T651 645 097 6483 TRANS,POWER,PULSE
COIL
!L601 645 099 6825 LINE FILTER
L611 910 244 3975 CORE
L612 945 077 6565 INDUCTOR,900U
945 084 0273 INDUCTOR,1400U
652 003 1821 INDUCTOR,1580UH
L614 910 244 3975 CORE
L615 910 244 3975 CORE
L616 910 244 3975 CORE
L631 910 078 5954 PIPE CORE
!LF601 645 093 1765 SOCKET,INLET AC 3P
DIODE
D611 407 267 4909 DIODE FML-S16S
D611C 645 098 1715 CORE,FERRITE
D613 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D631 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D632 307 247 8827 DIODE RF101L2S
307 190 4119 DIODE SFPL-52V
D633 308 061 8806 DIODE EG01C
D634 307 206 5413 ZD UDZS-TE-178.2B
D651 307 247 8827 DIODE RF101L2S
307 190 4119 DIODE SFPL-52V
D661 407 269 8400 DIODE FMEN-210A
407 267 3100 DIODE SG10SC9M
D662 407 269 8509 DIODE FMW-2106
407 267 3001 DIODE SG10SC6M
D663 307 247 8827 DIODE RF101L2S
307 190 4119 DIODE SFPL-52V
D664 307 210 5416 DIODE RB551V-30-TE-17
408 063 9600 DIODE RB551V-30
DB611 307 202 7708 DIODE D10XB60
MISCELLANEOUS
!F601 423 034 4101 FUSE 250V 6.3A
323 021 7804 FUSE 250V 6.3A
!F631 324 006 1305 FUSE 250V 2.5A
Q611F 645 098 1715 CORE,FERRITE
!PC661 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7)
!PC662 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7)
!PC663 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7
!PTH611 308 037 5501 THERMISTOR NTPDB50LDHB0
!PTH641 408 062 4606 TH PRF18BD471QB1RB
!SW601A 652 003 0244 ASSY,WIRE( SW601)
A1000 655 003 7275 ASSY,PWB,MAIN KR8AC
(For KR8-XD220000)
A1000 655 003 7237 ASSY,PWB,MAIN KS8AC
(For KS8-XD260000)
TRANSISTOR
Q1001 406 021 7804 TR 2SC4617
Q1002 406 021 7804 TR 2SC4617
Q1003 305 217 7815 TR HN1B04FE-Y TE85L
Q1004 305 217 7815 TR HN1B04FE-Y TE85L
Q1005 406 021 7804 TR 2SC4617
Q1006 305 217 7815 TR HN1B04FE-Y TE85L
Q1007 406 021 7804 TR 2SC4617
Q1008 406 021 7804 TR 2SC4617
Q1010 406 021 7804 TR 2SC4617
Q1011 406 021 7804 TR 2SC4617
Q1012 406 021 7804 TR 2SC4617
Q2001 406 021 7804 TR 2SC4617
Q2025 406 021 7804 TR 2SC4617
Q3582 305 217 6917 TR TPC6107 TE85L
Q3583 406 021 7804 TR 2SC4617
Q3601 406 021 7804 TR 2SC4617
Q4012 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q4014 305 217 7815 TR HN1B04FE-Y TE85L
Q5030 305 211 1918 TR RJU002N06
