Sanyo PLC-XTC50L - Part Names and Functions; Front; Back; Bottom

 Infrared Remote Receiver (Back)
 Lamp Cover
 Filter Cover
 Exhaust Vent
 Security Chain Hook
 Air Intake Vent
Hand Grip
10
Bottom
Back
DLens Release Button
JInfrared Remote Receiver (Top&Front)
8 Terminals and Connectors
ETop Controls and Indicators
G Lens Cover
LSpeaker
HProjection Lens(Optional)
<Adjustable Feet
BPower Cord Connector
 Optional Parts Attachment


CAUTION
Hot air is exhausted from the exhaust vent.
Do not put heat-sensitive objects near this
side.
L
J
8
Front
<
H
<
Part Names and Functions
L
G
E
D

B






=Kensington Security Slot
This slot is for a Kensington lock used
to deter theft of the projector.
* Kensington is a registered trademark of ACCO Brands
Corporation.
=
This is not a handle for carrying the projector.
Do not carry the projector with this hook.
