Sanyo PLC-XU355A User Manual

KG5-XU355A00, KB5-XU305A00
-107-
Mechanical Parts List
CABINET PARTS
C01 610 343 2045 ASSY STAND LEFT-KG5AC
C02 610 343 2052 ASSY STAND RIGHT-KG5AC
C03 610 344 3188 CABINET TOP SERVICE-KG5AC
C04 610 343 0959 BUTTON CONTROL-KG5AC
C05 610 343 0935 DEC INLAY LED-KG5AC
C06 610 343 0904 CABINET FRONT-KG5AC
C07 610 343 0881 CABINET BTM-KG5AC
C08 610 346 4268 CAP LENS-KG5AC
C09 610 344 3171 COVER ,LP SERVICE-KG5AC
C10 610 343 0942 DEC INLAY RC-KG5AC
C11 910 325 2477 DEC LEG-PT5EC
C12 610 343 0928 PANEL AV-KG5AC
C13 610 343 3943 FILTER BASE-KG5AC
C14 610 343 3950 PANEL NET B-KG5AC
C15 945 047 8032 BADGE,SANYO*26.2X5.7L26.0
CHASSIS PARTS
M01 610 342 5795 HOLDER INT PBS BTM-KG5AC
M02 610 342 5788 HOLDER INT PBS TOP-KG5AC
M03 610 343 1093 HOLDER LAMP HOUSE-KG5AC
M04 610 343 1109 HOLDER POW PWB-KG5AC
M05 610 343 1314 MTG RELAY OUT-KG5AC
M06 610 343 1307 MTG SPEAKER-KG5AC
M07 610 343 1352 MTG EXHAUST FAN-KG5AC
M08 610 343 1338 MOUNTING DUCT PNL TOP-KG5AC
M09 610 343 1369 MOUNTING DUCT PNL BTM-KG5AC
M10 610 343 1505 MOUNTING MCI-KG5AC
M11 610 342 5771 OPTICAL BASE BTM-KG5AC
M12 610 343 1086 OPTICAL BASE TOP-KG5AC
M13 610 343 1550 SPACER SHEET POWER TOP-KG5AC
M14 610 343 1543 SPACER SHEET FILTER A-KG5AC
M15 610 343 1390 SPACER_SHEET_POWER_BTM_KG5AC
M16 610 343 1581 SPACER SPONGE NET-KG5AC
M17 610 343 1345 MOUNTING DUCT LAMP TOP-KG5AC
M18 610 343 1376 MOUNTING DUCT LAMP BTM-KG5AC
SCREWS
S01 411 077 8606 SCR TPG FLT 3X8
S02 411 189 8907 SCR BIN 4X4
S03 411 031 9304 SCR BIN 3X8
S04 411 189 8303 SCR BIN 3X14
S05 412 077 8108 SPECIAL SCREW-2.5X6
S06 411 190 9108 SCR BIN 2X4
S07 312 070 3400 SPECIAL SCREW-3.0X10V
OPTICAL PARTS
L01 610 344 3195 ASSY PNL/PSM -KG5AC
(Including Key No. L01-R to L01-B)
L01-R 610 344 3393 COMPL P-POL R-KG5AC
L01-G 610 344 3386 COMPL POL G-KG5AC
L01-B 610 344 3409 COMPL POL B-KG5AC
L02-R 610 346 5562 ASSY,POL R IN-KG5AC
L02-G 610 346 5531 ASSY,POL G IN-KG5AC
L02-B 610 346 5548 ASSY,POL B IN-KD5AC
(For KG5-XU355A00)
L01 610 348 3474 ASSY PNL/PSM -KD5AE
(Including Key No. L01-R to L01-B)
L01-R 610 346 3148 COMPL P-POL R-KD5AC
L01-G 610 346 3131 COMPL POL G-KD5AC
L01-B 610 346 3155 COMPL POL B-KD5AC
L02-R 610 346 5562 ASSY,POL R IN-KG5AC
L02-G 610 346 5531 ASSY,POL G IN-KG5AC
L02-B 610 346 5548 ASSY,POL B IN-KD5AC
(For KB5-XU305A00)
L03 645 099 0588 LENS,INTEGRATOR(IN)
L04 945 086 6372 PRISM(PBS)
L05 645 099 0571 LENS,RELAY(IN)
L06 645 099 0601 LENS,RELAY(OUT)
L07 645 099 0595 LENS,INTEGRATOR(OUT)
L08 645 099 0564 LENS,CONDENSER(OUT)
L09 645 099 7396 DICHROIC MIRROR (B)
L10 645 099 7402 DICHROIC MIRROR (G)
L11 645 096 4657 LENS,CONDENSER(G)
L12 645 096 4718 MIRROR(R)
645 101 0254 MIRROR(R)
L13 645 096 4701 MIRROR(B)
645 101 0247 MIRROR(B)
L14 645 099 2568 LENS,PROJECTION
Key No. Part No. Description
Key No. Part No. Description
Mechanical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
