-23-
Optical Parts Disassembly
6
11
Fig.8
1
7
12
When mounting or assembling the optical parts in the opti-
cal unit, the parts must be mounted in the specified loca-
tion and direction as shown in figure below.
2
4
5
9
10
8. Locations and Directions
Poi n t marke r is
printed on this side
up.
Point marker is
printed on this side
up.
No. Parts Name
1 Integrator lens (IN)
2 Integrator lens (OUT)
3 Prism beam splitter (PBS)
4 Condenser lens (OUT)
5 Dichroic mirror (B)
6 Dichroic mirror (G)
7 Condenser lens (G)
8 Mirror (R)
9 Relay lens (IN)
10 Condenser lens (R)
11 Condenser lens (B)
12 Mirror (B)
8
Film attached side
is facing this side.
8
3
Rugged surface is
facing this side.
The rugged surface is
facing this side.
Poi n t marke r is
printed on this side
Poi n t marke r is
printed on this side
Poi n t marke r is
printed on this side
