KG5-XU355A00 , KB5-XU305A00
Electrical Parts List
-74-
Electrical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
Key No. Part No. Description Key No. Part No. Description
ASSEMBLED BOARDS
!A2300 655 002 7672 ASSY,PWB,NETWORK KB5AC
!A2400 655 002 7665 ASSY,PWB,MODULE KB5AC
!A2200 655 002 7641 ASSY,PWB,ANTENNA KB5AC
!A601 655 003 4335 ASSY,PWB,POWER KG5AE
!A602 655 003 4328 ASSY,PWB,FILTER KG5AE
!A1000 655 003 2812 ASSY,PWB,MIAN KG5AE
(For KG5-XU355A00)
!A1000 655 003 4281 ASSY,PWB,MAIN KB5AE
(For KB5-XU305A00)
!A1001 655 003 2805 ASSY,PWB,AV KG5AE
!A2800 655 003 2799 ASSY,PWB,R/C KG5AE
!A8700 655 003 2782 ASSY,PWB,ID CONNECT KG5AE
OUT OF CIRCUIT BOARD
L601 945 033 2228 CORE,FERRITE
!LP900 610 343 2069 COMPL,OPT LMP-KG5AC
!A901 645 099 2575 UNIT,BALLAST
A901A 610 344 5335 CABLE,BALLAST KG5AC
!FN901 645 099 5217 MOTOR,BLW DC 1.92W
!FN902 645 099 6160 MOTOR,FAN DC 3.36W
!FN903 645 099 6832 MOTOR,BLW DC 3.0W
!FN904 645 099 6849 MOTOR,BLW DC 3.0W
!FN905 645 099 6832 MOTOR,BLW DC 3.0W
!FN906 645 099 6856 MOTOR,FAN DC 3.36W
SP901 652 002 6445 SPEAKER,8
!SW901 645 097 3925 SWITCH,MICRO 1P-2T
!SW902 652 002 8852 SWITCH,THERMAL
Z9502&99
610 335 3111 CORD,SHIELD 1P
!Z6B&6C 652 002 8470 ASSY, WIRE(SW902)
655 002 7672 ASSY,PWB,NETWORK KB5AC
TRANSISTOR
Q5001 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q5002 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q8601 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC8101 409 696 0319 IC ISP1105BS
IC8201 409 695 9313 IC RT9711CGB
IC8301 410 641 3900 IC MC9328MX21VM
IC8303 309 301 5431 IC TC7S14FU(TE85L)
IC8304 309 301 5431 IC TC7S14FU(TE85L)
IC8451 410 650 3403 IC K4M283233H-HN75
410 650 3205 IC IS42S32400D-6BL
IC8501 410 677 5701 IC S29GL032N90TFI030KG5AC
IC8551 410 650 3403 IC K4M283233H-HN75
410 650 3205 IC IS42S32400D-6BL
IC8601 410 631 4405 IC EP2C35F484C8N
IC8801 410 677 1208 IC LAN9211-ABZJ
IC8902 309 553 4712 IC PQ070XZ02ZP
IC8932 309 670 5418 IC SI-3010KM
IC8933 309 670 5418 IC SI-3010KM
IC9601 309 334 0137 IC TC7W125FU
IC9701 310 428 4307 IC LM809M3-2.93
IC9711 309 334 0137 IC TC7W125FU
IC9712 410 656 8600 IC 24AA64T-I/MS
CAPACITOR
C5001 303 391 5511 ELECT 10U M 16V
C5002 303 391 5511 ELECT 10U M 16V
C5003 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C5004 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C5006 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C5007 403 455 5317 CERAMIC 6800P K 50V
303 454 0118 CERAMIC 6800P K 50V
303 441 9919 CERAMIC 6800P K 50V
C5008 403 455 5317 CERAMIC 6800P K 50V
303 454 0118 CERAMIC 6800P K 50V
303 441 9919 CERAMIC 6800P K 50V
C5009 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C5011 303 391 5511 ELECT 10U M 16V
C5012 303 391 5511 ELECT 10U M 16V
C8101 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C8102 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C8103 303 341 3918 POS-SOLID 100U M 6.3V
C8201 303 396 9613 CERAMIC 1U K 25V
403 478 5912 CERAMIC 1U K 25V
C8202 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C8203 403 455 1616 CERAMIC 10U K 16V
403 478 5813 CERAMIC 10U K 16V
C8301 303 276 2819 CERAMIC 18P J 50V
C8302 303 276 2819 CERAMIC 18P J 50V
C8303 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
To Next Page
