Sanyo PLC-XU355A User Manual

-38-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
0 Global Motion Sensitivity
Film Detection Sensitivity
<FILMSTVT23>
4 1 - 5
1 Video Motion Sensitivity
Film Detection Sensitivity
<VOFSTVT>
4 1 - 5
2 Video Motion Threshold Low <VOFTHRDA> 120 0 - 32767
3
Video Motion Threshold
High
<VOFTHRDB> 180 0 - 32767
4 Global Motion Threshold <GMDTHRD> 124 0 - 1024
5 23Film Mode Threshold <FILMTHRD23> 100 0 - 32767
6
Global Motion Window Start
X
<GMDSTARX> 10 0 - 2047 Range of detective for Film mode
7
Global Motion Window Stop
X
<GMDSTOPX> 10 0 - 2047 Range of detective for Film mode
8
Global Motion Window Start
Y
<GMDSTARY> 10 0 - 1023 Range of detective for Film mode
9
Global Motion Window Stop
Y
<GMDSTOPY> 10 0 - 1023 Range of detective for Film mode
Group
60
0 Center Contrast 512/556/534/534/492/492 0 - 1023
Video(S-Video) / Component /
SCART /
ANALOG / DIGITAL / HDCP
Setting Value=
(MENU Value - MENU Center Value
) x Alpha / 10 + Center
[Setting Value to PW]
Contrast [Max] 1023 [Min] 0
Brightness [Max] 1023 [Min] 0
Color [Max] 1023 [Min] 0
Tint [Max] 180 [Min] 0
Sharpness [Max] 57 [Min] 0
1 Center Brightness 512/480/512/500/512/512 0 - 1023
2 Center Color 512/534/512/512/512/512 0 - 1023
3 Center Tint 90/90/90/90/90/90 0-180
4 Center Sharpness 16/16/16/16/16/16 16
5 Alpha Contrast 40/40/40/40/40/40 0-1000
6 Alpha Brightness 70/70/70/70/70/70 0-1000
7 Alpha Color 70/70/70/70/70/70 0-1000
8 Alpha Tint 10/10/10/10/10/10 0-1000
9 Alpha Sharpness 10/10/10/10/10/10 0-1000
Group
100
Panel Service
0 G-SubGain
2048/2064/2000/2000/1950/1950/
1830/1900
0-4095
PCStandard/PCDynamic/PCReal/
PCBlackBoard/AVStandard/AVDy-
namic/AVCinema/AVBlackBoard
1 R-SubGain
2048/2064/2000/2000/1850/2048/
1950
0-4095
2 B-SubGain
2048/2064/2000/2000/2048/2000/
2048/2048
0-4095
3 G-SubBright 0/0/24/32/0/0/0/0 0-4095
PCStandard/PCDynamic/PCReal/
PCBlackBoard/AVStandard/AVDy-
namic/AVCinema/AVBlackBoard
4 R-SubBright 0/0/24/40/0/32/0/32 0-4095
5 B-SubBright 0/0/24/32/16/0/50/32 0-4095
6 G-GammaShift 0 0-4095
PC/AV
Center=512
R] and [B] are linked with [G]
7 R-GammaShift 0 0-4095
8 B-GammaShift 0 0-4095
9 G-ReferH 4000/4000 0-4095
[R] and [B] are linked with [G] Scan
Direction (Front/Rear)
10 G-ReferL 1048/1048 0-4095
[R] and [B] are linked with [G] Scan
Direction (Front/Rear)
11 R-ReferH 4000/4000 0-4095 Scan Direction (Front/Rear)
12 R-ReferL 1048/1048 0-4095 Scan Direction (Front/Rear)
13 B-ReferH 4000/4000 0-4095 Scan Direction (Front/Rear)
14 B-ReferL 1048/1048 0-4095 Scan Direction (Front/Rear)
15 DXOutR 234 0-1023
16 DXOutG 234 0-1023
17 DXOutB 234 0-1023
18 H_Change_Pos 30 0-255
19 SH_Base 273 0-4095
20 NRG_Pos 42 0-127
21 NRG_Width 31 0-255
22 OSD_Pos 2 0-3
23 OSD_Ptn 0 0-9
24 GammaCtrl 1 0-1
25 REF_GatePos 30 0-1023
26 REF_GateDur 130 0-1023
27 R-BasePos 8 0-15
28 G-BasePos 8 0-15
29 B-BasePos 8 0-15
30 RGB-Adjust 0 0-7
31 RGB-AdjLv 0 0-4095
Operation STEP=256[0<->256<->51
2<->768<->1023]
