Key No. Part No. Description Key No. Part No. Description
KG5-XU355A00 , KB5-XU305A00
Electrical Parts List
-82-
R674 301 264 7518 MT-GLAZE 2.7K FA 1/10W
R675 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R676 301 264 2810 MT-GLAZE 1.2K FA 1/10W
R683 301 265 0211 MT-GLAZE 390 FA 1/10W
R684 301 264 9314 MT-GLAZE 3.3K FA 1/10W
VARIABLE RESISTOR
!VR621 645 095 2579 VR,SEMI,1K N
645 102 0338 VR,SEMI,1K N
TRANSFORMER
!T651 645 097 6483 TRANS,POWER,PULSE
COIL
!L611 645 098 0473 LINE FILTER
L612 945 084 0273 INDUCTOR,1400U
L613 910 244 3975 CORE
L614 910 244 3975 CORE
L631 910 078 5954 PIPE CORE
L661 910 244 3975 CORE
L662 910 244 3975 CORE
L663 945 041 1978 INDUCTOR,330 OHM
DIODE
D611 307 191 3903 DIODE FML-G16S
D611D 645 098 1715 CORE,FERRITE
D611E 645 098 1715 CORE,FERRITE
D613 307 149 0810 DIODE 1SS355-TE-17
D631 307 149 0810 DIODE 1SS355-TE-17
D632 307 247 8827 DIODE RF101L2S
D633 307 146 8116 DIODE EG01C
D651 307 247 8827 DIODE RF101L2S
D661 407 261 9504 DIODE YG862C10R
D662 307 222 9607 DIODE FMB-2306
307 202 9801 DIODE FMB-26L
307 253 7504 DIODE RB085T-60
307 250 2403 DIODE RB225T-60
D663 307 247 8827 DIODE RF101L2S
307 190 4119 DIODE SFPL-52V
D664 307 210 5416 DIODE RB551V-30-TE-17
DB611 307 202 7708 DIODE D10XB60
MISCELLANEOUS
!F631 324 006 1305 FUSE 250V 2.5A
Q611F 645 098 1715 CORE,FERRITE
!PC661 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7)
!PC663 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7)
!PC671 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7)
PTH611 308 037 5501 THERMISTOR NTPDB5R0LDHB0
PTH641 408 062 4606 TH PRF18BD471QB1RB
ZD631 307 206 5413 ZD UDZS-TE-178.2B
655 003 4328 ASSY,PWB,FILTER KG5AE
CAPACITOR
!C601 404 117 6403 MT-POLYEST 1U K 275V
404 117 8902 MT-POLYEST 1U K 310V
!C602 404 117 6403 MT-POLYEST 1U K 275V
404 117 8902 MT-POLYEST 1U K 310V
!C603 304 073 3907 CERAMIC 1000P K 250V
!C604 304 073 3907 CERAMIC 1000P K 250V
RESISTOR
!R601 301 287 5416 MT-GLAZE 200K JA 1W
!R602 301 287 5416 MT-GLAZE 200K JA 1W
VARIABLE RESISTOR
!VA601 407 255 6304 VARISTOR MYG3-14K300ZT
408 061 9701 VARISTOR S14K300E2S5M4,2
COIL
!L601 645 099 6825 LINE FILTER
!LF601 645 093 1765 SOCKET,INLET AC 3P
MISCELLANEOUS
!F601 423 034 4101 FUSE 250V 6.3A
323 021 7804 FUSE 250V 6.3A
655 003 2812 ASSY,PWB,MAIN KG5AE
(For KG5-XU355A00)
655 003 4281 ASSY,PWB,MAIN KB5AE
(For KB5-XU305A00)
TRANSISTOR
Q036 406 021 7804 TR 2SC4617
Q037 406 021 7804 TR 2SC4617
Q1012 406 021 7804 TR 2SC4617
Q1021 406 021 7804 TR 2SC4617
Q1031 305 217 7815 TR HN1B04FE-Y TE85L
Q1041 305 217 7815 TR HN1B04FE-Y TE85L
Q1051 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q1062 406 021 7804 TR 2SC4617
Q1421 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q1422 406 021 7804 TR 2SC4617
Q2011 406 021 7804 TR 2SC4617
Q2021 406 021 7804 TR 2SC4617
Q2031 406 021 7804 TR 2SC4617
Q3051 406 021 7804 TR 2SC4617
Q3582 305 217 6917 TR TPC6107 TE85L
Q3583 406 021 7804 TR 2SC4617
Q3601 406 021 7804 TR 2SC4617
Q3801 305 191 5814 TR 3LN01C-TB-E
Q5031 406 021 7804 TR 2SC4617
Q5032 406 021 7804 TR 2SC4617
Q5035 405 221 7914 TR HN1C01FE-Y
Q5061 406 021 7804 TR 2SC4617
Q5062 406 021 7804 TR 2SC4617
Q5063 406 021 7804 TR 2SC4617
Q5064 406 021 7804 TR 2SC4617
Q5065 406 021 7804 TR 2SC4617
To Next Page
