5-2. Air Throw Distance Charts
Indoor unit SAP-KRV91EH
Horizontal distance (m)
Axis air velocity (m/s) Vertical distance (m)
Room air temp. : 20°C
Fan speed : High
Heating
Horizontal distance (m)
Axis air velocity (m/s) Vertical distance (m)
Room air temp. : 27°C
Fan speed : High
Cooling
0
1
2
3
4
0123456789
: Flap angle 0° , : Axis air velocity 0°
: Flap angle 30° , : Axis air velocity 30
0
1
2
3
4
0123456789
: Flap angle 45° , : Axis air velocity 45
: Flap angle 60° , : Axis air velocity 60
Flap angle 0°
Flap angle 30°
Axis air velocity 0°
Axis air velocity 30°
Flap angle 45°
Flap angle 60°
Axis air velocity 45°
Axis air velocity 60°
