4
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
2-2-2. Outdoor Unit
Outdoor unit SAP-CRV91EH
Control PCB POW-CV121CH
Compressor
Type Rotary (Hermetic)
Compressor model C-6RVN73HOT 80879680
Compressor oil … Amount cc FV68S … 350
Coil resistance (Ambient temp. 25°C) Ω C – R: 0.781
C – S: 0.781
Safety devices
CT (Peak current cut-off control) YES
Compressor discharge temp. control YES
Operation cut-off control in abnormal ambient temp. YES
Run capacitor µF —
VAC —
Crankcase heater —
Fan & Fan Motor
Type Propeller
Q’ty … Dia. mm 1 … ø400
Fan motor model … Q’ty DB8-33B280H … 1
No. of poles … rpm (230V, High) 8 … 730
Nominal output W 30
Coil resistance (Ambient temp. 20°C) Ω RED – WHT: 150.3
BLU – WHT: 150.3
BLU – RED: 150.3
Safety devices Type —
Operating temp. Open °C —
Close °C —
Run capacitor µF —
VAC —
Heat Exchanger Coil
Coil Aluminum plate fin / Copper tube
Rows 2
Fin pitch mm 1.4
Face area m
2
0.366
External Finish Acrylic baked-on enamel finish
To Next Page
