Operating Instructions Cubis
®
MCA 47
Installation
Requirements
− The weighing pan and the associated components have not been set up.
− For a device with an analytical draft shield or flat glass draft shield:
Theside panels and upper panel have not been fitted.
Procedure
t Turn the device on its side and place it on the soft support base.
t Remove the hook for below-balance weighing (1) from the retainer on
the underside of the base of the device.
t Pull the cover of the below-balance weighing equipment (1) out.
t NOTICE Damage to the device from cross-threading! Ensure that the
hook for below-balance weighing is inserted straight into the thread (1).
t Set up the device on the weighing table with recess.
The hook for below-balance weighing may not touch the floor.
t Install the draft protection shield.
1
1
1
