Sartorius eLINE - Pipette Description and Components; Display and Controls Explanation

5
Battery Cover
Charging
Contacts
Reset Button
Finger Hook
Tip Cone
(5000 µl)
Tip Ejector
Assembly
(5000 µl)
Display
Keyboard
Tip Ejection Buttons
Start Button
Handle
Handle Locking Collar
MCP Connecting Collar
Tip Ejector Collar
(10 µl –1000 µl)
Tip Cone Housing
Tip Ejector Bar
Tip Cone(s)
(excl. 5000 µl)
Safe-Cone Filter
Operating Mode Symbol
Mode Range
Aliquots/Counter Volume
Speed in/out Battery Symbol
Aspirating/Dispensing direction
Display:
4. Pipette Description
4.1. Display and Controls
The control and programming of the eLINE® pipette is
performed using the display, keyboard and operating
buttons.
