31
System Settings (Setup Menu)
Operating Instructions Moisture Analyzer MA160
Results
Results
Overview
Export
Delete
The analysis results can be viewed, exported, or deleted here.
Under Overview:
The saved results can be sorted, viewed or printed by date here.
t Select the desired entry.
t To print the displayed result, select a.
Under Export:
t Select this option to export the results. The data is exported in XML format.
Under Delete:
t Select this option to delete all saved results.
You are prompted to confirm.
t To delete the results, select YES.
Viewing Exported Data
You can open the data exported to the SD card as XML files with a browser and
view it there. The file is then displayed in table format in the browser (see figure on
the left).
Timeout Standby Temp.
Timeout Standby Temp.
2
1
3
Time [h]
The timeout for the standby temperature can be set here.
t To set the time, select t, enter the desired time and confirm with l (entry in
hours from 1 h to 24 h).
XML Structure
Version 0.6
Info
Model Number MA160-1
Seriel Number 0032202145
Version Balance 00-53-01.01.00
Version Display 01-80-01.09.00
Version Heater 07-40-05.00.00
Released
Released
YES
Method name
Method name Standard
End
End Fully automatic
Initial weight
Initial weight Off
Result display
Result display Moisture in %M
Target value
Target value Off
Standby temperature
Standby Off
No. of filters
No. of filters 0
Print lines
Print lines Off
Heating program
Type Standard drying
Temperature +130°C
METHOD
