Technical Specifications
Cubis MSE Operating Instructions 97
Model-specific Data
Verified models with EC Type Approval Certificate: Precision balances
Models MSE623S-0CE MSE623P-0CE MSE323S-0CE
Accuracy class* K K K
For verified models: EG-Type-Approval Certificate D09-09-015, Type: MSX
Scale interval d* mg 1 1/2/5 1
Weighing capacity max* g 620 150/300/620 320
Calibration value e* mg 10 10 10
Min� load min* mg 20 20 20
Tare equalization range (subtractive) < 100% from max� weighing capacity
Application range according to DIR* g 0�02 – 620 0�02 – 620 0�02 – 320
Optimal starting point
of the measuring range** g 0�82 0�82 0�82
Typical stabilization time s < 0�8 < 0�8 < 0�8
Typical measurement time s < 1 < 1 < 1
Application range (temperature) With “isoCAL” function: +5 to +40 °C | Without “isoCAL” function: +10 to +30 °C
Display result
(depending on the set filter level) 0�1 – 0�4
Weighing pan size (W + D) mm 140 + 140
Weighing chamber height (draft shield DE)
) mm 172
Protection Protected against dust and water
Models MSE14202S- MSE14202P- MSE10202S- MSE8202S-
0CE 0CE 0CE 0CE
Accuracy class* k k K K
For verified models: EC Type-Approval Certificate D09-09-015, Type: MSX
Scale interval d* g 0�01 0�01/0�02/0�05 0�01 0�01
Weighing capacity max* g 14,200 3,500/7,000/ 10,200 8,200
14,200
Calibration value e* g 0�1 0�1 0�1 0�1
Min� load min* g 1 1 1 0�5
Tare equalization range (subtractive) < 100% from max� weighing capacity
Application range according to DIR* g 1 – 14,200 1 – 14,200 1 – 10,200 0�5 – 8200
Optimal starting point
of the measuring range** g 8�2 8�2 8�2 8�2
Typical stabilization time s < 1 < 1 < 1 < 1
Typical measurement time s < 1�5 < 1�5 < 1�5 < 1�5
Application range (temperature):
With “isoCAL” function +5 to +40 °C +5 to +40 °C +5 to +40 °C +5 to +40 °C
Without “isoCAL” function +15 to +25 °C +15 to +25 °C +15 to +25 °C +10 to +30 °C
Display result
(depending on the set filter level) 0�1 – 0�4
Weighing pan size (W + D) mm 206 + 206
IP protection
(according to EN 60529/IEC 60529) IP54
* DIR = Directive 2014/31/EU on non-automatic weighing instruments used within the European Economic Area
** = According to USP (United States Pharmacopeia) section 41, the optimal measuring range is defined from 820 d to the max� weighing
range� Typically the value can be higher depending on the setup location and the ambient conditions�
