Example:
Totalizing weight values.
Settings (changes in the factory settings required for this example):
Application parameters: Application: Totalizing
Setup: Printout:
PrtProt: 7.6.
Setup: “Print when value stored”; then select menu line items of your choice
(see the chapter entitled “Configuration,” under “Printouts,” page 34)
Setup: Printout: “Total printout: Print when CF pressed;”
then select the menu line items of your choice (see “Configuration” for options)
1 Place the first weight on the
weighing platform
Weight value is displayed
O
2 Save the first weight value
in totalizing memory
G# + 0.250 kg The component data
T + 0.000 kg is printed automatically
N + 0.250 kg (configured printout)
n1
The transaction counter
value is increased by 1.
3 Remove the first weight from
the weighing platform
4 Place the second weight
on the weighing
Weight value is displayed
O
5 Save the second weight value
in totalizing memory
G# + 1.346 kg The component data
T + 0.346 kg is printed automatically
N + 1.000 kg (configured printout)
n2
The transaction counter value
is increased by one, to “2”
W
6 Toggle the display between
individual and total value
c
7 End totalizing
*G + 1.346 g The total data record is
*N + 1.250 g printed as configured.
n2
-------------------
73
