Appendix C Setpoint Triggers A N D A C T I O N S
146 PM130 PLUS Powermeter Series
High block kW import demand
High block kvar import demand
High sliding window kW import demand
High sliding window kvar import demand
High sliding window kVA demand
High accumulated kW import demand
High accumulated kvar import demand
High accumulated kVA demand
High predicted kW import demand
High predicted kvar import demand
High predicted kVA demand
Minute interval: 1-5, 10, 15, 20, 30, 60 min
1
In 4LN3, 3LN3 and 3BLN3 wiring modes, the voltages will be line-to-
neutral; for any other wiring mode, they will be line-to-line voltages.
Table 36: Setpoint Actions
Release latched relay RO1
Release latched relay RO2
