Chapter 3 Using F R O N T D I S P L A Y Data D I S P L A Y
50 PM130 PLUS Powermeter Series
This function is not operational if the meter is password protected and the
simple reset is not allowed in protected mode (see Configuring the
Display).
Common Measurements Display
Scroll through pages with the UP and DOWN arrow buttons.
Table 3: Common Measurements (Regular version)
1
L
V12
V23
V31
Line-to-line volts
2
P
V1
V2
V3
Line-to-neutral volts (in 4LN3,
3LN3, 3BLN3 configurations)
3
I1
I2
I3
Amps
4
kVA/MVA
PF
kW/MW
Total VA
Total PF
Total W
5
In
Hz
kvar/Mvar
Neutral current
Frequency
Total var
6
Ph.L1
PF
kW/MW
Phase L1 powers
(if enabled)
7
kVA/MVA
Ph.L1
kvar/Mvar
Phase L1 powers
(if enabled)
8
Ph.L2
PF
kW/MW
Phase L2 powers
(if enabled)
9
kVA/MVA
Ph.L2
kvar/Mvar
Phase L2 powers
(if enabled)
10
Ph.L3
PF
kW/MW
Phase L3 powers
(if enabled)
11
kVA/MVA
Ph.L3
kvar/Mvar
Phase L3 powers
(if enabled)
12
H01
PF
kW/MW
Fundamental total powers
(PM130EH, if enabled)
13
H1.L1
PF
kW/MW
Fundamental phase L1 powers
(PM130EH, if enabled)
14
H1.L2
PF
kW/MW
Fundamental phase L2 powers
(PM130EH, if enabled)
15
H1.L3
PF
kW/MW
Fundamental phase L3 powers
(PM130EH, if enabled)
16
U.Unb
V% unb
Voltage unbalance, percent
17
C.Unb
I% unb
Current unbalance, percent
