Chapter 3 Using FRO N T D I S P L A Y Data D I S P L A Y
PM130 PLUS Powermeter Series 51
Table 4: Common Measurements (Amp-Demand version)
Min/Max and Maximum Demand Display
1. Press the MAX/MIN button.
The MIN, MAX, or MAX DMD LED is illuminated when in the MIN/MAX
display.
2. Use the UP and DOWN arrow buttons to scroll through the Min/Max
and Max. Demand pages.
To see the time and date of the event occurrence:
1. Press simultaneously the SELECT and UP buttons.
2. Use the UP and DOWN arrow buttons to scroll through the
parameters displayed on the page. A corresponding LED at the right
is illuminated showing the parameter for which the timestamp is
displayed.
The time is displayed in format hh.mm, and the date in format MM-DD-YY
(default) or in any other format you can select via the display setup (see
Configuring the Display).
Note that Volts readings are line-to-neutral in 4LN3, 3LN3 and 3BLN3
wiring modes, and line-to-line in other modes.
Table 5: Min/Max and Maximum Demands (Regular version)
Minimum total VA
Minimum total PF (absolute)
Minimum total W
Minimum neutral current
Minimum frequency
Minimum total var
Maximum total VA
Maximum total PF (absolute)
Maximum total W
Maximum neutral current
Maximum frequency
Maximum total var
To Next Page
