Chapter 5 Configuring T H E P M 1 3 0 P L U S
Configuring C O M M U N I C A T I O N S
68 PM130 PLUS Powermeter Series
Chapter 5 Configuring the PM130
PLUS
This chapter describes how to configure different options in your meter
from the front panel display or via PAS.
5.1 Configuring Communications
Setting Up Serial Communication Ports
Using the Front Display
Select Prt1 for COM1 or Prt2 for COM2 from the main menu. See Viewing
and Changing Setup Options in Chapter 3 for information on configuring
parameters via the front display.
See Table 14 below for available communication options.
Using PAS
Select Communications Setup from the Meter Setup menu, and then
click on the Serial Ports Setup tab. In the Port box, select the desired
device port.
Figure 5-1: Communication Setup Dialog Box – Serial Ports Setup Tab
