Satec PM130 PLUS User Manual

Chapter 3 Using F R O N T D I S P L A Y Status D I S P L A Y
54 PM130 PLUS Powermeter Series
9
Ac.i 2
1234
56789
Phase L2 kWh import
10
rE.i 2
1234
56789
Phase L2 kvarh import
11
AP. 2
1234
56789
Phase L2 kVAh
12
Ac.i 3
1234
56789
Phase L3 kWh import
13
rE.i 3
1234
56789
Phase L3 kvarh import
14
AP. 3
1234
56789
Phase L3 kVAh
Table 11: TOU Energy Register 1
1
r1.t1
1234
56789
Tariff 1 reading
kWh
2
r1.t2
1234
56789
Tariff 2 reading
kWh
…
4
r1.t8
1234
56789
Tariff 8 reading
kWh
…
Table 12: TOU Energy Register 4
1
r4.t1
1234
56789
Tariff 1 reading
kWh
2
r4.t2
1234
56789
Tariff 2 reading
kWh
…
4
r4.t8
1234
56789
Tariff 8 reading
kWh
3.3 Status Display
The meter has a separate status information display accessible through
the primary meter menu. See Using the Menus for information on
navigating in menus.
