Chapter 5 Configuring T H E P M 1 3 0 P L U S
Configuring B I L L I N G / T O U
PM130 PLUS Powermeter Series 95
5.4 Configuring Billing/TOU
The TOU battery-backed clock unit is highly recommended in case of using
time-scheduled tariff rates, otherwise a long power outage may cause the
meter clock to lose time so your tariff counters would not comply with the
calendar schedule.
Billing Energy Registers
The PM130E/EH PLUS has 4 fully programmable billing energy registers
that can be linked to any internal energy source or to an external pulse
source that delivers pulses through the meter digital inputs.
Any energy register can provide either a single-tariff energy accumulation
or be individually linked to the TOU system providing both total and multi-
tariff energy billing.
Tariff Rates
The meter tariff structure supports 8 different tariff rates using an
arbitrary tariff schedule. A total of 4 types of days and 4 seasons are
supported with up to eight tariff changes per day.
Maximum Demand Registers
Any of billing energy registers can be individually linked to the maximum
demand register providing the same demand tariff structure as you
selected for energy registers.
Recording Billing Data and Load Profiling
The PM130E/EH PLUS can provide automatic recording of the daily energy
and maximum demand profile to a data log file. Maximum demand
profiling can be individually configured for every register.
See Factory Preset Data Log Files in Chapter 5 and Billing Profile Log File
in Appendix E for more information on the file layout and contents.
To configure the billing registers and the tariff system in your meter:
1. Link the billing registers to the respective energy sources.
2. Configure the options for the registers to whether the only
totalization or both total and tariff registers would be used, and
whether daily profiling should be enabled for the energy usage and
maximum demand registers.
3. Configure the daily tariff schedule using the TOU daily profiles for all
types of days and seasons.
4. Configure the season tariff schedule using the TOU calendar.
Configuring Billing/Tariff Registers
To configure the billing/TOU registers in your meter:
1. Select Energy/TOU from the Meter Setup menu.
