Unit 3: Command Quick Reference
SATO GL4xxe SBPL Programming Reference Page 3-14
LDa,b,c,d,e,f,g,i,jj User Download. Downloads a user defined set of Alternate Protocol
Command Codes. See Appendix E for details on the proper usage of this
command.
LFa Online Feed. To enable or disable online label feed.
a = 0: Enables label feed when online
1: Disables label feed when online
LHa Zero Slash. Allows printing zeroes with or without a slash.
a = 0: Prints zeroes without a slash
1: Prints zeroes with a slash
M Font type. Specifies the 13W x 20H dot matrix font (includes descenders).
NC Cutting Operation. Specifies the movement of cutting.
OA Font type. Specifies the OCR-A font.
OB Font type. Specifies the OCR-B font dot matrix.
OL Online. Changes the printer status from offline to online.
Paa Character Pitch. Designates the number of dots between characters.
aa = Number of dots between characters (01 to 99)
(aaaa,bbbb Reverse Image. Reverse image from black to white and vice versa. The
units of measure are dots.
aaaa = Horizontal length in dots of area to be reversed.
bbbb = Vertical height in dots of area to be reversed.
PCaa,bbPCF,a,........z Flash ROM Setup. Sets the default printer configuration in Flash ROM.
#Ea Print Darkness. Specifies a new print darkness setting.
%a Rotate, Fixed Base Reference Point.
a = 0: Sets print to normal direction.
1: Sets print to 90 degrees counter-clockwise.
2: Sets print to 180 degrees rotated (upside down)
3: Sets print to 270 degrees counter-clockwise (90x CW).
PG EEPROM Setup. Sets the default printer configuration in EEPROM.
PIaaa,bbbbb,cc...c PCX File, Store. Stores a PCX graphic file.
aaa = Storage number (001 to 999)
bbbbb = Number of bytes in the file to be stored.
cc...c =
PR Fixed Font Spacing. Returns the printer to fixed character spacing mode.
COMMAND QUICK REFERENCE
INSTRUCTION DESCRIPTION
