CURRENCY DISCRIMINATION COUNTER SB-7 (SB-1050) SERVICE MANUAL
1. DRIVING TEST
2. FEEDING TEST
In this mode, you can have a test if the machine detects the
input of key. Every time you press a key, the name of the
key will be displayed on LCD. However, in case of CLEAR
key, you exit from the current menu in stead of displaying.
In case that START key is pressed more than once, if
9(menu) key is pressed, you can exit from the current
1) Driving Test
You can run Main and Feed Motor in various speed.
2) Feeding Test
You can input notes (More then 5 number of notes) and test
the speed of each Motor. (Speed: 1000, 1200, 1500NPM)
The speed of Wing Stacker can change fast or slow (“±10”) by
pressing UP/DOWN key and press “START: key to save it.
To exit from current menu, press 9(menu) key.
1. WING 1000NPM
2. WING 1200NPM
3. WING 1500NPM
1.SELECTOR STACKER
2.SELECTOR REJECTOR
RED LED on the right of Front OPE lights and Selector sends the
notes to stacker.
2) Selector Rejecter
RED LED on the right of Front OPE is turned off and Selector
sends the notes to Rejecter.
2. KEY TEST
3. MOTOR TEST
4. SELECTOR TEST
5. WING SPEED SETTING
