SBM SB-7 - Chapter 12 Parts List

CURRENCY DISCRIMINATION COUNTER SB-7 (SB-1050) SERVICE MANUAL
- 52 -
12 Spare Parts List
O ; (Included), X ; (Not Included)
TYPE
SENSORS
IR MRS MRA UV
TYPE A O O O O
TYPE B O X O O
TYPE C O X X X
O ; (Included), X ; (Not Included)
Code Parts List Q'TY
Type
A
B
C
1A05X2148A ASS'Y_BKT_COVER_TOP 1 O
O
O
1A05X2149A ASS'Y_SHAFT_CASE_DETECTOR 1 O
O
O
1A05X2150A ASS'Y_BKT_SEPARATOR_P 1 O
O
O
1A05X2133A ASS'Y_BUSH_ONEWAY_BEARING_P 1 O
O
O
1A05X2131A ASS'Y_GUIDE_PRESS_ROLLER_P 1 O
O
O
1A05X2132A ASS'Y_GUIDE_TRANSFER_ROLLER_P 1 O
O
O
1A05X2124A ASS'Y_PULLEY_ADF_CLUTCH (W/ BEARING) 1 O
O
O
1A05X2138A ASS'Y_BKT_SMPS_BOTTOM 1 O
O
O
1A05X2137A ASS'Y_BKT_SMPS_TOP 1 O
O
O
1A05X2153A ASS'Y_OPE 1 O
O
O
1A05X2156A ASS'Y_COVER_DOOR_TOP 1 O
O
O
1A05X2157A ASS'Y_GUIDE_RACK 1 O
O
O
1A05X2155A ASS'Y_REJECT_PLATE 1 O
O
O
1A05X2154A ASS'Y_HOUSING_POCKET 1 O
O
O
1A05X2143A ASSY_COVER_SENSOR_IR 1 O
O
O
1A05X2144A ASSY_COVER_SENSOR_UV 1 O
O
O
1A05X2159A ASS'Y_MOTOR_FEED_P (W/ Pulley and Harness) 1 O
O
O
1A05X2158A ASS'Y_MOTOR_MAIN_P (W/ Pulley and Harness) 1 O
O
O
1A05X2134A ASS'Y_PLATE_BASE_P 1 O
O
O
1A05X2135A ASS'Y_PLATE_SIDE_L 1 O
O
O
1A05X2136A ASS'Y_PLATE_SIDE_R 1 O
O
O
Spare parts are sorted into by counterfeit sensors into 3 kinds of type as follows.
