SBM SB-7 - Cover Top

CURRENCY DISCRIMINATION COUNTER SB-7 (SB-1050) SERVICE MANUAL
- 72 -
13-13. Cover Top
1 ASS'Y_CASE_DETECTOR
2 SCREW_T/P_PH_T2_Ø3X8_Fe_Zy
3 E_RING_Ø5(5x11x0.6)_Fe_ZB
4 BUSH_REAR_HINGE
5 E_RING_Ø6(6x12x0.8)_Fe_ZB
6 BUSH_HINGE
7 BKT_COVER_TOP
8 ARM_ADJUST_UPPER
9 COIL_SPRING_ADJUST
10
SPECIAL_SCREW_ADJUST
11
SCREW_M/C_PH/SWW_M3X8_Fe_Zy
12
COVER_SADDLE_DS-2
13
ASS'Y_BKT_SEPARATOR_P
