CURRENCY DISCRIMINATION COUNTER SB-7 (SB-1050) SERVICE MANUAL
- 9 -
2 Description of the Parts
2-1. Out Side
2-2. Interface Port
PORT INTERFACE
RJ11 Connected with Customer Display
RS232C Connected with Printer or PC
USB(Type B) Connected with PC in Dual User mode
USB(Type A) USB MEMORY (Program Upgrade )
