VERSION 01. 00
CHECKSUM OK
OC28
A/S NO.
321 7654 9876
1-4. Setting Up Your Machine
1-4-1. Power Cord
Plug one end of the cord into the back of the machine and the
other end into a standard AC power outlet.
If you turn on the power switch, the machine will display version
and checksum. If there is Service Call number saved by a service
provider, the Call number will be displayed.
1-4-2. Printer
Your SB-7 has a serial interface port, which allows you to
connect the printer to print out counting result. To connect the printer to the machine, follow the steps below:
1. Make sure that both the SB-7 and the printer are turned off.
2. Plug the cable of printer into the serial port of SB-7.
3. Turn on the printer and SB-7.
CAUTION
In case that another port is used to avoid electrical shock, turn off SB-7 and turn on
the machine after Port is connected.
