CURRENCY DISCRIMINATION COUNTER SB-7 (SB-1050) SERVICE MANUAL
- 27 -
SERVICE MENU2
1. SENSOR TEST
2. KEY TEST
3. MOTOR TEST
4. SELECTOR TEST
5. WING SPEED SETTING
8 SERVICE MENU 2
There are Service Menu1 and Service Men2 in Service Menu.
Service Menu2 includes the menu to have a test for development or for repair.
8-1. How to enter SERVICE MENU 2:
8-2. Service Menu2
Press : 9→MODE→ ***** →DISPLAY
To exit from the current function, press ‘9(menu)’ key and to move SERVICE MENU1, press ‘MODE’
key.
< Display of SERVICE MENU 2 >
1. SENSOR TEST
------------------------
1) LED TEST
A. HOPPER LED ON
B. HOPPER LED OFF
C. SENSOR LED ON
D. SENSOR LED OFF
2) HOPPER TEST
3) SENSOR LOGIC TEST
4) IR LOGIC TEST
5) IRA TEST
2. KEY TEST
3. MOTOR TEST
--------------------------
1) DRIVING TEST / 2) FEEDING TEST
4. SELECTOR TEST
--------------------- 1) SELECTOR STACKER / 2) SELECTOR REJECTOR
5. WING SPEED SETTING
-------------
1) WING 1000NPM / 2) WING 1200NPM / 3) WING 1500NPM
